DC Charger

Growing concern of carbon dioxide emissions, greenhouse effects and rapid depletion of fossil fuels raise the necessity to produce and adopt new eco- friendly sustainable alternatives to the internal combustion engine (ICE) driven vehicles. For this reason, in the last decade, EVs have become in some way widespread, principally because of their negligible fuel gas emissions and lesser reliance on oil. Not only the choice of the charging technology, but also the selection of the correct charging method is a feature that has to be considered during the charging procedure.  As a result, some promising charging strategies which are based on complete models of lithium-ion batteries we are providing.

 Product Type
Wattage Ratings Product code Efficiency Size (L X B X H)
 Waterproof
150W 24V (2-5)A NEV-150WP-LX-24 >91% 200 x 51 x 35
 Forced Cooling
300W 24V (2-9)A NEV-300NWP-LX-24 >89% 172 x 78 x 46

 Multi stage charging (Pre-Charge, CC & CV) with Equalization

 Wide Input Range (90V – 280V)

 Automatic Output Current De-rating at Lower Input Voltage

 LCD Display for Charging Status and Error Status

 >91% efficiency at Full Load

 Charger starts from OV (BMS cutoff)

 Robust Protection For Over Current, Short Circuit, Input Over Voltage, Output Over Voltage, Reverse Battery Protection, Surge 4KV and EMI

 CAN Enabled (RS-485 optional)

  Electric Bicycles

 Electric Scooters & Bike

 Electric Rickshaw

Growing concern of carbon dioxide emissions, greenhouse effects and rapid depletion of fossil fuels raise the necessity to produce and adopt new eco- friendly sustainable alternatives to the internal combustion engine (ICE) driven vehicles. For this reason, in the last decade, EVs have become in some way widespread, principally because of their negligible flue gas emissions and lesser reliance on oil. Not only the choice of the charging technology, but also the selection of the correct charging method is a feature that has to be considered during the charging procedure.  As a result, some promising charging strategies which are based on complete models of lithium-ion batteries we are providing.

 Product Type
Wattage Ratings Product code Efficiency Size (L X B X H)
 Waterproof
150W 36V (2-3.5)A NEV-150WP-LX-36 >91% 200 x 51 x 35
 Forced Cooling
300W 36V (2-7)A NEV-300NWP-LX-36 >89%
172 x 78 x 46

 Multi stage charging (Pre-Charge, CC & CV) with Equalization

 Wide Input Range (90V – 280V)

 Automatic Output Current De-rating at Lower Input Voltage

 LCD Display for Charging Status and Error Status

 >91% efficiency at Full Load

 Charger starts from OV (BMS cutoff)

 Robust Protection For Over Current, Short Circuit, Input Over Voltage, Output Over Voltage, Reverse Battery Protection, Surge 4KV and EMI

 CAN Enabled (RS-485 optional)

  Electric Bicycles

 Electric Scooters & Bike

 Electric Rickshaw

Growing concern of carbon dioxide emissions, greenhouse effects and rapid depletion of fossil fuels raise the necessity to produce and adopt new eco- friendly sustainable alternatives to the internal combustion engine (ICE) driven vehicles. For this reason, in the last decade, EVs have become in some way widespread, principally because of their negligible flue gas emissions and lesser reliance on oil. Not only the choice of the charging technology, but also the selection of the correct charging method is a feature that has to be considered during the charging procedure.  As a result, some promising charging strategies which are based on complete models of lithium-ion batteries we are providing.

 Product Type
Wattage Ratings Product code Efficiency Size (L X B X H)

 Waterproof

150W 48V (2-3)A NEV-150WP-LX-48 >91%
200 x 51 x 35
900W
48V (10-15)A NEV-900WP-LX-48 >91% 190 x 140 x 114
Forced Cooling 300W 48V (2-5)A NEV-300NWP-LX-48 >89% 172 x 78 x 46
  600W 48V (6-10)A NEV-600NWP-LX-48 >89%
214 x 122 x 57

900W 48V (11-15)A NEV-900NWP-LX-48 >91%
268 x 122 x 57
  1800W 48V (16-25)A NEV-1800NWP-LX-48 >91%
278 x 149 x 90
  3300W 48V (26-45)A NEV-3300NWP-LX-48 >91% 420 x 148 x 90

 Multi stage charging (Pre-Charge, CC & CV) with Equalization

 Wide Input Range (90V – 280V)

 Automatic Output Current De-rating at Lower Input Voltage

 LCD Display for Charging Status and Error Status

 >91% efficiency at Full Load

 Charger starts from OV (BMS cutoff)

 Robust Protection For Over Current, Short Circuit, Input Over Voltage, Output Over Voltage, Reverse Battery Protection, Surge 4KV and EMI

 CAN Enabled (RS-485 optional)

  Electric Bicycles

 Electric Scooters & Bike

 Electric Rickshaw

 48V Series
Approved
NEV-1KPNW-LX-48.docx
 48V Series
Approved
NEV-300NW-LX-48.docx
 48V Series
Approved
NEV-1KNW-LX-48.docx
 48V Series
Approved
NEV-150NW-LX-48.docx
 48V Series
Approved
NEV-15KPNW-LX-48.docx
 48V Series
Approved
NEV-400NW-LX-48.docx
 48V Series
Approved
NEV-700NW-LX-48.docx
 48V Series
Approved
NEV-600NW-LX-48.docx

Growing concern of carbon dioxide emissions, greenhouse effects and rapid depletion of fossil fuels raise the necessity to produce and adopt new eco- friendly sustainable alternatives to the internal combustion engine (ICE) driven vehicles. For this reason, in the last decade, EVs have become in some way widespread, principally because of their negligible fuel gas emissions and lesser reliance on oil. Not only the choice of the charging technology, but also the selection of the correct charging method is a feature that has to be considered during the charging procedure.  As a result, some promising charging strategies which are based on complete models of lithium-ion batteries we are providing.

 Product Type
Wattage Ratings Product code Efficiency Size (L X B X H)
 Waterproof
900W
60V (8-12)A NEV-900WP-LX-60 >91% 190 x 140 x 114
Forced Cooling 300W 60V (2-4)A NEV-300NW-LX-60 >89%
172 x 78 x 46
  420W 60V (5)A NEV-600NWP-LX-60 >89%
197 x 122 x 57
  600W 60V (6-8)A NEV-600NWP-LX-60 >89%
214 x 122 x 57

900W 60V (9-12)A NEV-900NWP-LX-60 >91%
268 x 122 x 57
  1800W 60V (12-20)A NEV-1800NWP-LI-60 >91%
278 x 149 x 90
  3300W 60V (21-45)A NEV-3300NWP-LX-60 >91%
420 x 148 x 90

 Multi stage charging (Pre-Charge, CC & CV) with Equalization

 Wide Input Range (90V – 280V)

 Automatic Output Current De-rating at Lower Input Voltage

 LCD Display for Charging Status and Error Status

 >91% efficiency at Full Load

 Charger starts from OV (BMS cutoff)

 Robust Protection For Over Current, Short Circuit, Input Over Voltage, Output Over Voltage, Reverse Battery Protection, Surge 4KV and EMI

 CAN Enabled (RS-485 optional)

  Electric Bicycles

 Electric Scooters & Bike

 Electric Rickshaw

Growing concern of carbon dioxide emissions, greenhouse effects and rapid depletion of fossil fuels raise the necessity to produce and adopt new eco- friendly sustainable alternatives to the internal combustion engine (ICE) driven vehicles. For this reason, in the last decade, EVs have become in some way widespread, principally because of their negligible fuel gas emissions and lesser reliance on oil. Not only the choice of the charging technology, but also the selection of the correct charging method is a feature that has to be considered during the charging procedure.  As a result, some promising charging strategies which are based on complete models of lithium-ion batteries we are providing.

 Product Type
Wattage Ratings Product code Efficiency Size (L X B X H)
 Waterproof
1000W 72V (2-6)A NEV-1000WP-LX-72  >91%
235 x 65 x 42

3300W
72V (7-10)A NEV-3300WP-LX-72 >91% 190 x 140 x 114
Forced Cooling 300W 72V (2-3)A NEV-300NWP-LX-72 >89%
172 x 78 x 46
  420W 72V (5-8A) NEV-420NWP-LX-72 >89%
197 x 122 x 57

600W 72V (6-10)A NEV-600NWP-LX-72 >89%
214 x 122 x 57
  900W 72V (8-10)A NEV-900NWP-LX-72 >91%
268 x 122 x 57
  1800W 72V (11-15)A NEV-1800NWP-LX-72 >91%
278 x 149 x 90
  3300W 72V (15-38)A  NEV-3300NWP-LX-72 >91%
420 x 148 x 90

 Multi stage charging (Pre-Charge, CC & CV) with Equalization

 Wide Input Range (90V – 280V)

 Automatic Output Current De-rating at Lower Input Voltage

 LCD Display for Charging Status and Error Status

 >91% efficiency at Full Load

 Charger starts from OV (BMS cutoff)

 Robust Protection For Over Current, Short Circuit, Input Over Voltage, Output Over Voltage, Reverse Battery Protection, Surge 4KV and EMI

 CAN Enabled (RS-485 optional)

  Electric Bicycles

 Electric Scooters & Bike

 Electric Rickshaw
